Ferrari Purosangue Europe - REAR SUSPENSION - ARMS

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
800828 COMPL. LH REAR HUB CARRIER $2,559.11 To Order
800829 COMPL. RH REAR HUB CARRIER $2,559.11 To Order
Photo Part No Description Price (each) Stock
971876 COMPL. LOWER LH REAR ARM $1,459.27 To Order
971905 COMPL. LOWER RH REAR ARM $1,459.27 To Order
Photo Part No Description Price (each) Stock
950508 LH ACTUATOR $5,450.32 To Order
950509 RH ACTUATOR $5,733.82 To Order
Photo Part No Description Price (each) Stock
15541434 SCREW 12.1 X 25 X 80 $1.83 IN STOCK
Photo Part No Description Price (each) Stock
14496721 WASHER $0.09 IN STOCK
Photo Part No Description Price (each) Stock
203666 NUT $0.81 IN STOCK
Photo Part No Description Price (each) Stock
302406 THREADED ROD $2.11 IN STOCK
Photo Part No Description Price (each) Stock
13578321 WASHER $0.46 IN STOCK
Photo Part No Description Price (each) Stock
14496524 WASHER D.8.4 X 17 X 1.6 $0.11 IN STOCK
Photo Part No Description Price (each) Stock
104030 NUT $0.24 IN STOCK
Photo Part No Description Price (each) Stock
859105 LH REAR SENSOR BRACKET $56.93 To Order
859109 RH REAR SENSOR BRACKET $56.93 To Order
Photo Part No Description Price (each) Stock
12642701 Washer $0.05 To Order
Photo Part No Description Price (each) Stock
741924 NUT $7.94 To Order
Photo Part No Description Price (each) Stock
833066 ACTUATOR CABLE FASTENER BRACKET $41.74 To Order
Photo Part No Description Price (each) Stock
81911600 SCREW $0.44 To Order
Photo Part No Description Price (each) Stock
883878 COMPL. REAR UPPER ARM $442.95 To Order
Photo Part No Description Price (each) Stock
264528 THREADED ROD $3.40 IN STOCK
Photo Part No Description Price (each) Stock
312826 WASHER $0.41 To Order
Photo Part No Description Price (each) Stock
14496624 WASHER D.10.5-21 X 2 $0.06 IN STOCK
Photo Part No Description Price (each) Stock
104114 NYLOCK HEX. NUT M10 X 1.25 X 12 $0.38 IN STOCK
Photo Part No Description Price (each) Stock
250657 SCREW $7.07 IN STOCK
Photo Part No Description Price (each) Stock
338394 LH REAR JOINT BRACKET $25.29 To Order
338395 RH REAR JOINT BRACKET $25.29 To Order
Photo Part No Description Price (each) Stock
13046011 NUT $0.32 To Order
Photo Part No Description Price (each) Stock
336026 ABS SENSOR $66.96 To Order
Photo Part No Description Price (each) Stock
942843 LH ABS CABLE BRACKET $3.92 To Order
942906 RH ABS CABLE BRACKET $3.92 To Order
Photo Part No Description Price (each) Stock
259688 ANTI-ROTATION LINKAGE $183.08 IN STOCK
Photo Part No Description Price (each) Stock
238258 SCREW $28.77 IN STOCK
Photo Part No Description Price (each) Stock
222956 COMPENSATOR RING $16.44 To Order
Photo Part No Description Price (each) Stock
238656 SPECIAL SCREW TCEI M14 X 1.5 X 21 $24.34 IN STOCK
Photo Part No Description Price (each) Stock
238063 NUT $3.92 IN STOCK
Photo Part No Description Price (each) Stock
896438 THREADED ROD $3.30 IN STOCK
Photo Part No Description Price (each) Stock
888754 ADJUSTER SHIM $8.10 To Order
888755 ADJUSTER SHIM $9.28 To Order
888756 ADJUSTER SHIM $10.12 To Order
...and 5 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
969297 ADJUSTMENT SHIM $20.25 To Order
969298 ADJUSTMENT SHIM $21.93 To Order
969299 ADJUSTMENT SHIM $23.63 To Order
...and 5 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
13507434 WASHER $1.10 To Order
Photo Part No Description Price (each) Stock
148020 NUT M12 X 1.25 $3.83 To Order
Photo Part No Description Price (each) Stock
984045 COMPL. TRAVEL SENSOR $180.71 To Order
Photo Part No Description Price (each) Stock
216973 BALL JOINT $3.34 IN STOCK
Photo Part No Description Price (each) Stock
16284934 FLANGED SCREW $0.70 IN STOCK
View All
REAR SUSPENSION - ARMS of Ferrari Ferrari Purosangue Europe Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
0001 800828
COMPL. LH REAR HUB CARRIER 		$2,559.11 1
0001 800829
COMPL. RH REAR HUB CARRIER 		$2,559.11 1
0002 971876
COMPL. LOWER LH REAR ARM 		$1,459.27 1
0002 971905
COMPL. LOWER RH REAR ARM 		$1,459.27 1
0003 950508
LH ACTUATOR 		$5,450.32 1
0003 950509
RH ACTUATOR 		$5,733.82 1
0004 15541434
SCREW 12.1 X 25 X 80
M12 X 1.25 X 80
IN STOCK 		$1.83 (38.6% off) 4
0005 14496721
WASHER
IN STOCK 		$0.09 6
0006 203666
NUT
IN STOCK 		$0.81 (59.5% off) 4
0007 302406
THREADED ROD
IN STOCK 		$2.11 4
0008 13578321
WASHER
IN STOCK 		$0.46 4
0009 14496524
WASHER D.8.4 X 17 X 1.6
IN STOCK 		$0.11 (92.7% off) 4
0010 104030
NUT
IN STOCK 		$0.24 (76% off) 4
0011 859105
LH REAR SENSOR BRACKET 		$56.93 1
0011 859109
RH REAR SENSOR BRACKET 		$56.93 1
0012 12642701
Washer 		$0.05 2
0013 741924
NUT 		$7.94 2
0014 833066
ACTUATOR CABLE FASTENER BRACKET 		$41.74 2
0015 81911600
SCREW
M6 X 1 X 18 		$0.44 2
0016 883878
COMPL. REAR UPPER ARM 		$442.95 2
0017 264528
THREADED ROD
IN STOCK 		$3.40 (13.9% off) 4
0018 312826
WASHER 		$0.41 4
0019 14496624
WASHER D.10.5-21 X 2
D. 10.5-21 X 2
IN STOCK 		$0.06 4
0020 104114
NYLOCK HEX. NUT M10 X 1.25 X 12
IN STOCK 		$0.38 (24% off) 4
0021 250657
SCREW
M6 X 14
IN STOCK 		$7.07 6
0022 338394
LH REAR JOINT BRACKET 		$25.29 1
0022 338395
RH REAR JOINT BRACKET 		$25.29 1
0023 13046011
NUT 		$0.32 2
0024 336026
ABS SENSOR 		$66.96 2
0026 942843
LH ABS CABLE BRACKET 		$3.92 1
0026 942906
RH ABS CABLE BRACKET 		$3.92 1
0027 259688
ANTI-ROTATION LINKAGE
IN STOCK 		$183.08 2
0028 238258
SCREW
M12 X 1.25 X 75
IN STOCK 		$28.77 2
0029 222956
COMPENSATOR RING 		$16.44 2
0030 238656
SPECIAL SCREW TCEI M14 X 1.5 X 21
M14 X 1.5 X 210
IN STOCK 		$24.34 (11.1% off) 2
0031 238063
NUT
IN STOCK 		$3.92 (28.7% off) 2
0032 896438
THREADED ROD
IN STOCK 		$3.30 8
0033 888754
ADJUSTER SHIM
Th. 0.5 mm 		$8.10 4
0033 888755
ADJUSTER SHIM
Th. 1 mm 		$9.28 4
0033 888756
ADJUSTER SHIM
Th. 1.5 mm 		$10.12 4
0033 888757
ADJUSTER SHIM
Th. 2 mm 		$10.97 4
0033 888758
ADJUSTER SHIM
Th. 2.5 mm 		$10.97 4
0033 888759
ADJUSTER SHIM
Th. 3 mm 		$11.81 4
0033 888760
ADJUSTER SHIM
Th. 3.5 mm 		$12.65 4
0033 888761
ADJUSTER SHIM
Th. 4 mm 		$13.49 4
0034 969297
ADJUSTMENT SHIM
Th. 0.5 mm 		$20.25 2
0034 969298
ADJUSTMENT SHIM
Th. 1 mm 		$21.93 2
0034 969299
ADJUSTMENT SHIM
Th. 1.5 mm 		$23.63 2
0034 969296
ADJUSTMENT SHIM
Th. 2 mm 		$26.16 2
0034 969300
ADJUSTMENT SHIM
Th. 2.5 mm 		$27.84 2
0034 969301
ADJUSTMENT SHIM
Th. 3 mm 		$31.21 2
0034 969302
ADJUSTMENT SHIM
Th. 3.5 mm 		$34.60 2
0034 969303
ADJUSTMENT SHIM
Th. 4 mm 		$35.44 2
0035 13507434
WASHER 		$1.10 8
0036 148020
NUT M12 X 1.25 		$3.83 8
0037 984045
COMPL. TRAVEL SENSOR 		$180.71 2
0038 216973
BALL JOINT
IN STOCK 		$3.34 (25.8% off) 2
0039 16284934
FLANGED SCREW
M5 X 10
IN STOCK 		$0.70 4
