Front Suspension - Shock Absorber And Brake Disc

Ferrari GTC4Lusso

Find Your Part

Ferrari GTC4Lusso - FRONT SUSPENSION - SHOCK ABSORBER AND BRAKE DISC

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
309803 FRONT SHOCK ABSORBER $1,851.48 To Order
309804 FRONT SHOCK ABSORBER $2,301.77 To Order
Photo Part No Description Price (each) Stock
326481 SPRING $188.65 To Order
55013734 SPRING $145.65 To Order
Photo Part No Description Price (each) Stock
274308 STOP CAP $233.93 IN STOCK
Photo Part No Description Price (each) Stock
212517 UPPER SPACER SHOCK ABSORBER $11.10 IN STOCK
Photo Part No Description Price (each) Stock
211236 LOWER SPRING SPACER $29.88 IN STOCK
Photo Part No Description Price (each) Stock
157630 SHOCK ABSORBER BUSH $109.15 IN STOCK
Photo Part No Description Price (each) Stock
288828 END STOP BUSH $68.87 IN STOCK
Photo Part No Description Price (each) Stock
261914 RH STRUT OF SHOCK ABSORBER FOR 4WD $389.91 To Order
261913 LH STRUT OF SHOCK ABSORBER FOR 4WD $389.91 To Order
Photo Part No Description Price (each) Stock
300214 ACTUATOR SHOCK ABSORBER LIFT $1,237.33 IN STOCK
Photo Part No Description Price (each) Stock
260408 RUBBER PIPE $56.58 To Order
Photo Part No Description Price (each) Stock
261587 HOSE $30.17 IN STOCK
Photo Part No Description Price (each) Stock
259638 GASKET $13.20 IN STOCK
Photo Part No Description Price (each) Stock
15541234 SCREW $1.44 IN STOCK
Photo Part No Description Price (each) Stock
259664 WASHER $5.28 To Order
Photo Part No Description Price (each) Stock
259711 BUSHING $10.91 To Order
Photo Part No Description Price (each) Stock
263315 RH BRACKET $22.62 To Order
263314 LH BRACKET $22.62 To Order
Photo Part No Description Price (each) Stock
261214 CLIP $1.17 To Order
Photo Part No Description Price (each) Stock
248790 SCREW $3.46 IN STOCK
Photo Part No Description Price (each) Stock
237297 SCREW $26.00 IN STOCK
Photo Part No Description Price (each) Stock
237821 BUSH $4.16 IN STOCK
Photo Part No Description Price (each) Stock
255271 NUT $1.21 IN STOCK
Photo Part No Description Price (each) Stock
12646921 WASHER $0.50 IN STOCK
Photo Part No Description Price (each) Stock
339613 FRONT AXLE SHAFT $2,996.07 To Order
Photo Part No Description Price (each) Stock
203780 HUB NUT HEX M28 $23.04 IN STOCK
Photo Part No Description Price (each) Stock
303385 CLIP $0.26 IN STOCK
Photo Part No Description Price (each) Stock
315457 BRAKE DISC FRONT CERAMIC $4,488.91 IN STOCK
Photo Part No Description Price (each) Stock
260676 RH FRONT BRAKE DISC SHIELD $40.23 To Order
260675 LH FRONT BRAKE DISC SHIELD $40.23 To Order
Photo Part No Description Price (each) Stock
250657 SCREW $7.02 IN STOCK
Photo Part No Description Price (each) Stock
228131 SCREW $0.71 IN STOCK
Photo Part No Description Price (each) Stock
104370 SCREW $8.66 IN STOCK
Photo Part No Description Price (each) Stock
228132 SPRING WASHER $0.30 IN STOCK
Photo Part No Description Price (each) Stock
268410 PLATE $7.52 To Order
Photo Part No Description Price (each) Stock
14306931 SCREW $0.82 To Order
Photo Part No Description Price (each) Stock
10397680 CABLE GROMMET $0.80 To Order
Photo Part No Description Price (each) Stock
260586 ABS CABLE GUIDE BRACKET $17.60 To Order
Photo Part No Description Price (each) Stock
265000 STABILISER BAR $389.91 To Order
Photo Part No Description Price (each) Stock
236241 ROLL BAR RUBBER BUSH 20 X 36 $28.52 IN STOCK
Photo Part No Description Price (each) Stock
245822 BUSHING RETAINER PLATE $22.62 IN STOCK
Photo Part No Description Price (each) Stock
247950 LH SPHERICAL TIE-ROD $101.36 IN STOCK
247952 RH SPHERICAL TIE-ROD $101.36 IN STOCK
Photo Part No Description Price (each) Stock
10791014 NUT $0.26 To Order
Photo Part No Description Price (each) Stock
12601474 WASHER $0.03 IN STOCK
Photo Part No Description Price (each) Stock
264117 SCREW $2.43 IN STOCK
Photo Part No Description Price (each) Stock
286144 BUSHING MOUNT $23.88 To Order
Photo Part No Description Price (each) Stock
70006025 GAITER REPLACEMENT KIT $127.81 To Order
70006024 GAITER REPLACEMENT KIT $127.81 To Order
View All
FRONT SUSPENSION - SHOCK ABSORBER AND BRAKE DISC of Ferrari Ferrari GTC4Lusso Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
1 309803
FRONT SHOCK ABSORBER 		$1,851.48 2
1 309804
FRONT SHOCK ABSORBER
Version with lifter 		$2,301.77 2
2 326481
SPRING
Version with lifter 		$188.65 2
2 55013734
SPRING 		$145.65 2
3 274308
STOP CAP
IN STOCK 		$233.93 2
4 212517
UPPER SPACER SHOCK ABSORBER
IN STOCK 		$11.10 2
5 211236
LOWER SPRING SPACER
IN STOCK 		$29.88 2
6 157630
SHOCK ABSORBER BUSH
IN STOCK 		$109.15 (28.3% off) 2
7 288828
END STOP BUSH
IN STOCK 		$68.87 2
8 261914
RH STRUT OF SHOCK ABSORBER FOR 4WD 		$389.91 1
8 261913
LH STRUT OF SHOCK ABSORBER FOR 4WD 		$389.91 1
9 300214
ACTUATOR SHOCK ABSORBER LIFT
Version with lifter
IN STOCK 		$1,237.33 2
10 260408
RUBBER PIPE
Version with lifter 		$56.58 2
11 261587
HOSE
Version with lifter
IN STOCK 		$30.17 (64.4% off) 2
12 259638
GASKET
Version with lifter
IN STOCK 		$13.20 (20.2% off) 4
13 15541234
SCREW
M12 X 1.25 X 70
IN STOCK 		$1.44 2
14 259664
WASHER 		$5.28 2
15 259711
BUSHING 		$10.91 2
16 263315
RH BRACKET 		$22.62 1
16 263314
LH BRACKET 		$22.62 1
17 261214
CLIP 		$1.17 2
18 248790
SCREW
IN STOCK 		$3.46 4
19 237297
SCREW
M12 X 1.25 X 80
IN STOCK 		$26.00 2
20 237821
BUSH
IN STOCK 		$4.16 (24.4% off) 2
21 255271
NUT
IN STOCK 		$1.21 (16.6% off) 2
22 12646921
WASHER
IN STOCK 		$0.50 2
23 339613
FRONT AXLE SHAFT 		$2,996.07 2
24 203780
HUB NUT HEX M28
IN STOCK 		$23.04 (10.7% off) 2
25 303385
CLIP
Fastening wear indicator cable
IN STOCK 		$0.26 2
26 315457
BRAKE DISC FRONT CERAMIC
IN STOCK 		$4,488.91 2
27 260676
RH FRONT BRAKE DISC SHIELD 		$40.23 1
27 260675
LH FRONT BRAKE DISC SHIELD 		$40.23 1
28 250657
SCREW
M6 X 14
IN STOCK 		$7.02 4
29 228131
SCREW
M8 X 20
IN STOCK 		$0.71 2
30 104370
SCREW
IN STOCK 		$8.66 2
31 228132
SPRING WASHER
IN STOCK 		$0.30 4
32 268410
PLATE 		$7.52 12
33 14306931
SCREW
M8 X 50 		$0.82 24
34 10397680
CABLE GROMMET
No longer supplied 		$0.80 2
35 260586
ABS CABLE GUIDE BRACKET 		$17.60 2
36 265000
STABILISER BAR 		$389.91 1
37 236241
ROLL BAR RUBBER BUSH 20 X 36
IN STOCK 		$28.52 (27.8% off) 2
38 245822
BUSHING RETAINER PLATE
IN STOCK 		$22.62 2
39 247950
LH SPHERICAL TIE-ROD
On lower LH arm
IN STOCK 		$101.36 (9.5% off) 1
39 247952
RH SPHERICAL TIE-ROD
On lower RH arm
IN STOCK 		$101.36 (9.5% off) 1
40 10791014
NUT 		$0.26 2
41 12601474
WASHER
IN STOCK 		$0.03 4
42 264117
SCREW
M10 X 1.25 X 30
IN STOCK 		$2.43 4
43 286144
BUSHING MOUNT 		$23.88 2
44 70006025
GAITER REPLACEMENT KIT
Gearbox side 		$127.81 2
44 70006024
GAITER REPLACEMENT KIT
Wheel/gearbox side 		$127.81 2
