Air Intake

Ferrari 812 Superfast/GTS

Find Your Part

Ferrari 812 Superfast/GTS - AIR INTAKE

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
823879 AIR DUCT $1,518.66 To Order
823866 AIR DUCT $1,470.96 To Order
342366 AIR DUCT $1,537.99 To Order
...and 1 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
223039 Air Filter $104.42 ARRIVING SOON
812789 AIR FILTER $259.88 ARRIVING SOON
812789 AIR FILTER $259.88 ARRIVING SOON
...and 1 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
88831000 GRUB SCREW M5 X 40 $0.49 IN STOCK
897538 SCREW $1.54 To Order
Photo Part No Description Price (each) Stock
333295 AIR FILTER COVER $128.91 To Order
333296 AIR FILTER COVER $4,191.15 To Order
Photo Part No Description Price (each) Stock
86321000 WASHER $5.32 To Order
Photo Part No Description Price (each) Stock
15699804 SCREW $0.19 IN STOCK
Photo Part No Description Price (each) Stock
296781 PIPE CLAMP 30-45MM $7.90 ARRIVING SOON
Photo Part No Description Price (each) Stock
270296 MEMBRANE HOLDER PIPE $42.53 To Order
Photo Part No Description Price (each) Stock
175119 BRACKET WITH SHEATH $6.68 To Order
Photo Part No Description Price (each) Stock
338528 RH FASTENER BRACKET $18.03 To Order
338620 RH FASTENER BRACKET $24.48 To Order
Photo Part No Description Price (each) Stock
338529 LH FASTENER BRACKET $18.03 To Order
338624 LH FASTENER BRACKET $24.48 To Order
Photo Part No Description Price (each) Stock
336067 LH RESONATOR PIPE FASTENER BRACKET $20.61 To Order
Photo Part No Description Price (each) Stock
339297 COILED PIPE $123.74 To Order
Photo Part No Description Price (each) Stock
339296 COILED PIPE $121.16 To Order
Photo Part No Description Price (each) Stock
293051 COILED PIPE $148.13 To Order
Photo Part No Description Price (each) Stock
336066 RH RESONATOR PIPE FASTENER BRACKET $20.61 To Order
Photo Part No Description Price (each) Stock
330023 LH DUCT MOUNTING BRACKET $21.91 To Order
Photo Part No Description Price (each) Stock
330024 RH DUCT MOUNTING BRACKET $21.91 To Order
Photo Part No Description Price (each) Stock
336068 BRACKET $21.91 To Order
Photo Part No Description Price (each) Stock
303385 CLIP $0.26 IN STOCK
Photo Part No Description Price (each) Stock
262114 HOSE CLAMP $1.06 IN STOCK
View All
AIR INTAKE of Ferrari Ferrari 812 Superfast/GTS Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
1 823879
AIR DUCT
Applicable for EU GS, AUS, CINA, USA, CDN, GOLFO, UK, USA LIGHT; Applicable from Ass. No. 156813 		$1,518.66 1
1 823866
AIR DUCT
Not for EU GS, AUS, CINA, USA, CDN, GOLFO, UK, USA LIGHT; Applicable from Ass. No. 156813 		$1,470.96 1
1 342366
AIR DUCT
Applicable for CINA, USA, CDN, GOLFO, USA LIGHT; Applicable up to Ass. No. 156812 		$1,537.99 1
1 340702
AIR DUCT
Not for CINA, USA, CDN, GOLFO, USA LIGHT; Applicable up to Ass. No. 156812 		$1,490.29 1
2 223039
Air Filter
Applicable for EU GS, AUS, UK; Applicable up to Ass. No. 152775
ARRIVING SOON 		$104.42 2
2 812789
AIR FILTER
Applicable for EU GS, AUS, UK; Applicable from Ass. No. 152776
ARRIVING SOON 		$259.88 2
2 812789
AIR FILTER
Applicable for USA, CDN, USA LIGHT
ARRIVING SOON 		$259.88 2
2 223039
Air Filter
Not for EU GS, AUS, USA, CDN, UK, USA LIGHT
ARRIVING SOON 		$104.42 2
3 88831000
GRUB SCREW M5 X 40
M5 X 25
IN STOCK 		$0.49 4
3 897538
SCREW
M5 X 20 		$1.54 10
4 333295
AIR FILTER COVER 		$128.91 2
4 333296
AIR FILTER COVER
Applicable for carbon filter box cover 		$4,191.15 2
5 86321000
WASHER
Applicable for carbon filter box cover 		$5.32 12
6 15699804
SCREW
IN STOCK 		$0.19 4
7 296781
PIPE CLAMP 30-45MM
Applicable up to Ass. No. 156812
ARRIVING SOON 		$7.90 2
8 270296
MEMBRANE HOLDER PIPE
D. 38; Applicable up to Ass. No. 156812 		$42.53 4
9 175119
BRACKET WITH SHEATH
Applicable up to Ass. No. 156812 		$6.68 4
10 338528
RH FASTENER BRACKET 		$18.03 1
10 338620
RH FASTENER BRACKET
Applicable for carbon filter box cover 		$24.48 1
11 338529
LH FASTENER BRACKET 		$18.03 1
11 338624
LH FASTENER BRACKET
Applicable for carbon filter box cover 		$24.48 1
12 336067
LH RESONATOR PIPE FASTENER BRACKET
Applicable up to Ass. No. 156812 		$20.61 1
13 339297
COILED PIPE
Applicable up to Ass. No. 156812 		$123.74 2
14 339296
COILED PIPE
Applicable up to Ass. No. 156812 		$121.16 2
15 293051
COILED PIPE
Applicable up to Ass. No. 156812 		$148.13 2
16 336066
RH RESONATOR PIPE FASTENER BRACKET
Applicable up to Ass. No. 156812 		$20.61 1
17 330023
LH DUCT MOUNTING BRACKET 		$21.91 1
18 330024
RH DUCT MOUNTING BRACKET 		$21.91 1
19 336068
BRACKET
Applicable up to Ass. No. 156812 		$21.91 2
20 303385
CLIP
Applicable up to Ass. No. 156812
IN STOCK 		$0.26 8
21 262114
HOSE CLAMP
Applicable up to Ass. No. 156812
IN STOCK 		$1.06 10
