Name: Fuel tanks
Rating: 5.0 (1 reviews)

View All

Ferrari 512 TR - Fuel tanks

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	146946	Fill tube	$172.43	To Order

Photo	Part No	Description	Price (each)	Stock
	174095	GASKET	$5.47	To Order

Photo	Part No	Description	Price (each)	Stock
	13276470	SCREW M6 X 20	$0.29	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	11197774	WASHER	$0.06	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	10902424	SCREW	$0.14	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	14059290	FLANGED NUT M6	$1.31	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	12646604	WASHER	$0.21	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	146943	Tube	$63.46	To Order

Photo	Part No	Description	Price (each)	Stock
	141033	GASKET	$21.41	To Order

Photo	Part No	Description	Price (each)	Stock
	12182290	SCREW COLLAR	$0.41	To Order

Photo	Part No	Description	Price (each)	Stock
	146967	R.H. fuel tank	$1,580.03	To Order

Photo	Part No	Description	Price (each)	Stock
	148095	L.H. fuel tank	$1,720.32	To Order

Photo	Part No	Description	Price (each)	Stock
	144849	Gauge	$506.96	To Order

Photo	Part No	Description	Price (each)	Stock
	154802	TANK SENDER GASKET	$30.06	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	121435	RING NUT	$141.36	To Order

Photo	Part No	Description	Price (each)	Stock
	148045	FUEL DRAIN PLUG	$17.85	To Order

Photo	Part No	Description	Price (each)	Stock
	123622	O-Ring	$1.38	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	180320	COPMLETE TANK PLUG	$632.11	To Order

Photo	Part No	Description	Price (each)	Stock
	154023	Tube	$123.28	To Order

Photo	Part No	Description	Price (each)	Stock
	13000590	SCREW COLLAR	$0.68	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	147244	Tube	$14.02	To Order

Photo	Part No	Description	Price (each)	Stock
	142106	GASKET	$7.96	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	13432870	COLLAR FOR HOSE UNION	$11.53	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	147246	VENT PIPE FROM TANK TO	$270.78	To Order

Photo	Part No	Description	Price (each)	Stock
	142106	GASKET	$7.96	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	13432870	COLLAR FOR HOSE UNION	$11.53	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	117873	Tube	$21.10	To Order

Photo	Part No	Description	Price (each)	Stock
	262111	SCREW CLAMP	$1.38	To Order

Photo	Part No	Description	Price (each)	Stock
	147946	R.H. bracket	$43.77	To Order

Photo	Part No	Description	Price (each)	Stock
	147947	L.H. bracket	$43.24	To Order

Photo	Part No	Description	Price (each)	Stock
	147948	Spacer	$1.25	To Order

Photo	Part No	Description	Price (each)	Stock
	115734	Plate	$1.44	To Order

Photo	Part No	Description	Price (each)	Stock
	14059290	FLANGED NUT M6	$1.31	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	122797	Strap fuel tank	$23.73	To Order

Photo	Part No	Description	Price (each)	Stock
	213177	THREADED TIE-ROD	$33.50	To Order

Photo	Part No	Description	Price (each)	Stock
	264555	SPLIT PIN	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	104030	NUT	$0.24	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	103447	PIN	$1.66	To Order

Photo	Part No	Description	Price (each)	Stock
	125036	RUBBER THICKNESS	$4.07	To Order

Photo	Part No	Description	Price (each)	Stock
	125037	Spacer	$1.66	To Order

Photo	Part No	Description	Price (each)	Stock
	125035	RUBBER THICKNESS	$2.57	To Order

Photo	Part No	Description	Price (each)	Stock
	146974	R.H. panel -Not for GD-	$88.19	To Order

Photo	Part No	Description	Price (each)	Stock
	146975	L.H. panel -Not for GD-	$88.19	To Order

Photo	Part No	Description	Price (each)	Stock
	897538	SCREW	$1.52	To Order

Photo	Part No	Description	Price (each)	Stock
	127494	WASHER	$0.08	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	12643724	WASHER	$0.06	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	60758600	NUT	$0.49	To Order

Photo	Part No	Description	Price (each)	Stock
	153150	R.H. shield -Valid for J-	$218.62	To Order

Photo	Part No	Description	Price (each)	Stock
	153151	Central shield -Valid for J-	$501.68	To Order

Photo	Part No	Description	Price (each)	Stock
	153152	L.H. shield -Valid for J-	$753.75	To Order

Photo	Part No	Description	Price (each)	Stock
	153155	Lower bracket -Valid for J-	$17.36	To Order

Photo	Part No	Description	Price (each)	Stock
	153156	R.H. lower bracket	$10.38	To Order

Photo	Part No	Description	Price (each)	Stock
	153154	Upper bracket -Valid for J-	$17.36	To Order

Photo	Part No	Description	Price (each)	Stock
	14059290	FLANGED NUT M6	$1.31	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	12644424	WASHER	$0.06	IN STOCK

View All

Diagram Tap to enlarge

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
-	150382	L.H. panel -Valid for GD-	150382 L.H. panel -Valid for GD-	$120.93	1
-	150381	R.H. panel -Valid for GD-	150381 R.H. panel -Valid for GD-	$120.93	1
-	154802	TANK SENDER GASKET IN STOCK	154802 TANK SENDER GASKET Valid after stock exhaustion / of 132132 IN STOCK	$30.06 MSRP: ~~37.09~~ (19% off)	1
-	151611	Fill tube	151611 Fill tube Valid for SA and ZA	$263.96	1
1	146946	Fill tube	146946 Fill tube Not for SA and ZA	$172.43	1
2	174095	GASKET	174095 GASKET	$5.47 MSRP: ~~5.98~~ (8.5% off)	1
3	13276470	SCREW M6 X 20 IN STOCK	13276470 SCREW M6 X 20 IN STOCK	$0.29 MSRP: ~~0.75~~ (61.3% off)	3
4	11197774	WASHER IN STOCK	11197774 WASHER IN STOCK	$0.06 MSRP: ~~0.30~~ (80% off)	3
5	10902424	SCREW IN STOCK	10902424 SCREW IN STOCK	$0.14 MSRP: ~~0.70~~ (80% off)	1
6	14059290	FLANGED NUT M6 IN STOCK	14059290 FLANGED NUT M6 IN STOCK	$1.31	1
7	12646604	WASHER IN STOCK	12646604 WASHER IN STOCK	$0.21 MSRP: ~~0.30~~ (30% off)	2
8	146943	Tube	146943 Tube	$63.46 MSRP: ~~348.77~~ (81.8% off)	1
9	141033	GASKET	141033 GASKET	$21.41 MSRP: ~~42.00~~ (49% off)	2
10	12182290	SCREW COLLAR	12182290 SCREW COLLAR	$0.41	2
11	146967	R.H. fuel tank	146967 R.H. fuel tank	$1,580.03	1
12	148095	L.H. fuel tank	148095 L.H. fuel tank	$1,720.32	1
13	144849	Gauge	144849 Gauge	$506.96	1
14	154802	TANK SENDER GASKET IN STOCK	154802 TANK SENDER GASKET IN STOCK	$30.06 MSRP: ~~37.09~~ (19% off)	1
15	121435	RING NUT	121435 RING NUT	$141.36	1
16	148045	FUEL DRAIN PLUG	148045 FUEL DRAIN PLUG	$17.85 MSRP: ~~27.58~~ (35.3% off)	2
17	123622	O-Ring IN STOCK	123622 O-Ring IN STOCK	$1.38	2
18	180320	COPMLETE TANK PLUG	180320 COPMLETE TANK PLUG	$632.11 MSRP: ~~822.01~~ (23.1% off)	1
19	154023	Tube	154023 Tube	$123.28	1
20	13000590	SCREW COLLAR IN STOCK	13000590 SCREW COLLAR IN STOCK	$0.68	2
21	147244	Tube	147244 Tube	$14.02	1
22	142106	GASKET IN STOCK	142106 GASKET IN STOCK	$7.96 MSRP: ~~11.25~~ (29.2% off)	2
23	13432870	COLLAR FOR HOSE UNION IN STOCK	13432870 COLLAR FOR HOSE UNION IN STOCK	$11.53	2
24	147246	VENT PIPE FROM TANK TO	147246 VENT PIPE FROM TANK TO	$270.78	1
25	142106	GASKET IN STOCK	142106 GASKET IN STOCK	$7.96 MSRP: ~~11.25~~ (29.2% off)	2
26	13432870	COLLAR FOR HOSE UNION IN STOCK	13432870 COLLAR FOR HOSE UNION IN STOCK	$11.53	2
27	117873	Tube	117873 Tube	$21.10	1
28	262111	SCREW CLAMP	262111 SCREW CLAMP	$1.38	2
29	147946	R.H. bracket	147946 R.H. bracket	$43.77	2
30	147947	L.H. bracket	147947 L.H. bracket	$43.24	2
31	147948	Spacer	147948 Spacer	$1.25	4
32	115734	Plate	115734 Plate	$1.44	4
33	14059290	FLANGED NUT M6 IN STOCK	14059290 FLANGED NUT M6 IN STOCK	$1.31	8
34	122797	Strap fuel tank	122797 Strap fuel tank	$23.73	4
35	213177	THREADED TIE-ROD	213177 THREADED TIE-ROD	$33.50	4
36	264555	SPLIT PIN	264555 SPLIT PIN	-	12	Enquire
37	104030	NUT IN STOCK	104030 NUT IN STOCK	$0.24 MSRP: ~~1.00~~ (76% off)	4
38	103447	PIN	103447 PIN	$1.66	4
39	125036	RUBBER THICKNESS	125036 RUBBER THICKNESS	$4.07	9
40	125037	Spacer	125037 Spacer	$1.66	4
41	125035	RUBBER THICKNESS	125035 RUBBER THICKNESS	$2.57	4
42	146974	R.H. panel -Not for GD-	146974 R.H. panel -Not for GD-	$88.19	1
43	146975	L.H. panel -Not for GD-	146975 L.H. panel -Not for GD-	$88.19	1
44	897538	SCREW	897538 SCREW	$1.52	18
45	127494	WASHER IN STOCK	127494 WASHER IN STOCK	$0.08 MSRP: ~~0.68~~ (88.2% off)	18
46	12643724	WASHER IN STOCK	12643724 WASHER IN STOCK	$0.06 MSRP: ~~0.50~~ (88% off)	18
47	60758600	NUT	60758600 NUT	$0.49 MSRP: ~~1.55~~ (68.4% off)	4
48	153150	R.H. shield -Valid for J-	153150 R.H. shield -Valid for J-	$218.62	1
49	153151	Central shield -Valid for J-	153151 Central shield -Valid for J-	$501.68	1
50	153152	L.H. shield -Valid for J-	153152 L.H. shield -Valid for J-	$753.75	1
51	153155	Lower bracket -Valid for J-	153155 Lower bracket -Valid for J-	$17.36	3
52	153156	R.H. lower bracket	153156 R.H. lower bracket Valid for J	$10.38	1
53	153154	Upper bracket -Valid for J-	153154 Upper bracket -Valid for J-	$17.36	3
54	14059290	FLANGED NUT M6 IN STOCK	14059290 FLANGED NUT M6 IN STOCK	$1.31	11
55	12644424	WASHER IN STOCK	12644424 WASHER IN STOCK	$0.06 MSRP: ~~0.40~~ (85% off)	11

Fuel Tanks

Ferrari 512 TR

Ferrari 512 TR - Fuel tanks
