Brake System -Not For Gd-

Ferrari 456 M GT/GTA

Find Your Part

Ferrari 456 M GT/GTA - BRAKE SYSTEM -Not for GD-

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
163145 FRONT TOOTHED WHEEL SENSOR $227.29 To Order
Photo Part No Description Price (each) Stock
60909500 ALLEN HEAD SCREW M6 X 15 $1.96 IN STOCK
Photo Part No Description Price (each) Stock
127494 WASHER $0.08 IN STOCK
Photo Part No Description Price (each) Stock
137313 R.H. and L.H. front flexible pipe $367.69 To Order
Photo Part No Description Price (each) Stock
116374 CLIP $2.19 IN STOCK
Photo Part No Description Price (each) Stock
163146 REAR TOOTHED WHEEL SENSOR $72.31 To Order
Photo Part No Description Price (each) Stock
60909500 ALLEN HEAD SCREW M6 X 15 $1.96 IN STOCK
Photo Part No Description Price (each) Stock
127494 WASHER $0.08 IN STOCK
Photo Part No Description Price (each) Stock
215411 CLIP $1.35 To Order
Photo Part No Description Price (each) Stock
271771 PIPE Enquire To Order
Photo Part No Description Price (each) Stock
116374 CLIP $2.19 IN STOCK
Photo Part No Description Price (each) Stock
178480 BRAKE PIPE FROM PUMP TO ABS CENTER UNIT $18.15 To Order
Photo Part No Description Price (each) Stock
143055 FIXING CLIP $0.60 To Order
Photo Part No Description Price (each) Stock
178479 BRAKE PIPE FROM PUMP TO PRESSURE SWITCH $8.46 To Order
Photo Part No Description Price (each) Stock
212645 CLIP $3.01 To Order
Photo Part No Description Price (each) Stock
175004 BRAKE PIPE FROM ABS CENTER UNIT TO RH FRONT FLEXIBLE PIPE $13.64 To Order
Photo Part No Description Price (each) Stock
141505 FIXING CLIP $0.81 To Order
Photo Part No Description Price (each) Stock
175002 BRAKE PIPE FROM REGULATOR ABS CENTER UNIT $15.12 To Order
Photo Part No Description Price (each) Stock
10104661 3-WAY UNION $4.50 To Order
Photo Part No Description Price (each) Stock
14059290 FLANGED NUT M6 $1.32 IN STOCK
Photo Part No Description Price (each) Stock
12639724 WASHER $0.05 IN STOCK
Photo Part No Description Price (each) Stock
154309 PRESSURE REGULATOR $37.83 To Order
Photo Part No Description Price (each) Stock
175005 BRAKE PIPE FROM ABS CENTER UNIT TO LH FRONT FLEXIBLE PIPE $17.74 To Order
Photo Part No Description Price (each) Stock
175006 BRAKE PIPE FROM ABS CENTER UNIT TO UNION FOR RH REAR BRAKE $24.07 To Order
Photo Part No Description Price (each) Stock
175007 BRAKE PIPE FROM ABS CENTER UNIT TO UNION FOR LH REAR BRAKE $24.07 To Order
Photo Part No Description Price (each) Stock
169152 UNION $240.89 To Order
Photo Part No Description Price (each) Stock
15896470 NUT $6.35 To Order
Photo Part No Description Price (each) Stock
127493 WASHER $0.06 To Order
Photo Part No Description Price (each) Stock
175008 BRAKE PIPE FROM UNION TO RH REAR FLEXIBLE PIPE $25.34 To Order
Photo Part No Description Price (each) Stock
175009 BRAKE PIPE FROM UNION TO LH REAR FLEXIBLE PIPE $22.80 To Order
Photo Part No Description Price (each) Stock
148835 Buffer $13.93 To Order
Photo Part No Description Price (each) Stock
168148 REAR SENSOR PROTECTION $48.44 To Order
Photo Part No Description Price (each) Stock
10519424 WASHER D.6.4 X 11.95 X 1.6 $0.02 IN STOCK
Photo Part No Description Price (each) Stock
150738 CLIP $0.54 To Order
Photo Part No Description Price (each) Stock
212645 CLIP $3.01 To Order
View All
BRAKE SYSTEM -Not for GD- of Ferrari Ferrari 456 M GT/GTA Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
- 178988
BRAKE PIPE FROM JOINT TO LH REAR FLEXIBLE PIPE
L.H. REAR FLEXIBLE PIPE / Valid from car Ass. Nr. 35055 		$18.15 1
- 178986
BRAKE PIPE FROM ABS CENTER UNIT TO LH REAR BRAKE JOINT
TO L.H. REAR BRAKE JOINT / Valid from car Ass. Nr. 35055 		$137.74 1
- 183369
BRAKE PIPE FROM JOINT TO RH REAR FLEXIBLE PIPE
R.H. REAR FLEXIBLE PIPE / Valid from car Ass. Nr. 35055 		$22.69 1
- 178985
BRAKE PIPE FROM ABS CENTER UNIT TO RH REAR BRAKE JOINT
TO R.H. REAR BRAKE JOINT / Valid from car Ass. Nr. 35055 		$137.74 1
1 163145
FRONT TOOTHED WHEEL SENSOR
SENSOR 		$227.29 2
2 60909500
ALLEN HEAD SCREW M6 X 15
IN STOCK 		$1.96 (34.4% off) 2
3 127494
WASHER
IN STOCK 		$0.08 (88.2% off) 2
4 137313
R.H. and L.H. front flexible pipe 		$367.69 2
5 116374
CLIP
IN STOCK 		$2.19 (37.4% off) 4
6 163146
REAR TOOTHED WHEEL SENSOR
SENSOR 		$72.31 (22.8% off) 2
7 60909500
ALLEN HEAD SCREW M6 X 15
IN STOCK 		$1.96 (34.4% off) 6
8 127494
WASHER
IN STOCK 		$0.08 (88.2% off) 6
9 215411
CLIP 		$1.35 4
10 271771
PIPE 		- 2 Enquire
11 116374
CLIP
IN STOCK 		$2.19 (37.4% off) 4
12 178480
BRAKE PIPE FROM PUMP TO ABS CENTER UNIT
ABS CENTER UNIT 		$18.15 1
13 143055
FIXING CLIP
Valid till car Ass. Nr. 35054 		$0.60 3
14 178479
BRAKE PIPE FROM PUMP TO PRESSURE SWITCH
PRESSURE SWITCH 		$8.46 1
15 212645
CLIP 		$3.01 7
16 175004
BRAKE PIPE FROM ABS CENTER UNIT TO RH FRONT FLEXIBLE PIPE
CENTER UNIT TO R.H. FRONT / FLEXIBLE PIPE 		$13.64 1
17 141505
FIXING CLIP 		$0.81 (67.7% off) 3
18 175002
BRAKE PIPE FROM REGULATOR ABS CENTER UNIT
ABS CENTER UNIT 		$15.12 1
19 10104661
3-WAY UNION 		$4.50 1
20 14059290
FLANGED NUT M6
IN STOCK 		$1.32 1
21 12639724
WASHER
IN STOCK 		$0.05 (90% off) 1
22 154309
PRESSURE REGULATOR 		$37.83 (24.3% off) 1
23 175005
BRAKE PIPE FROM ABS CENTER UNIT TO LH FRONT FLEXIBLE PIPE
TO L.H. FRONT FLEXIBLE PIPE / Valid till car Ass. Nr. 35054 		$17.74 1
24 175006
BRAKE PIPE FROM ABS CENTER UNIT TO UNION FOR RH REAR BRAKE
TO UNION FOR R.H. REAR BRAKE / Valid till car Ass. Nr. 35054 		$24.07 1
25 175007
BRAKE PIPE FROM ABS CENTER UNIT TO UNION FOR LH REAR BRAKE
TO UNION FOR L.H. REAR BRAKE / Valid till car Ass. Nr. 35054 		$24.07 1
26 169152
UNION
Valid till car Ass. Nr. 35054 		$240.89 1
27 15896470
NUT
Valid till car Ass. Nr. 35054 		$6.35 1
28 127493
WASHER
Valid till car Ass. Nr. 35054 		$0.06 (80% off) 1
29 175008
BRAKE PIPE FROM UNION TO RH REAR FLEXIBLE PIPE
R.H. REAR FLEXIBLE PIPE / Valid till car Ass. Nr. 35054 		$25.34 1
30 175009
BRAKE PIPE FROM UNION TO LH REAR FLEXIBLE PIPE
L.H. REAR FLEXIBLE PIPE / Valid till car Ass. Nr. 35054 		$22.80 1
31 148835
Buffer
Valid till car Ass. Nr. 35054 		$13.93 (36.7% off) 1
32 168148
REAR SENSOR PROTECTION 		$48.44 2
33 10519424
WASHER D.6.4 X 11.95 X 1.6
IN STOCK 		$0.02 (92% off) 4
34 150738
CLIP 		$0.54 6
35 212645
CLIP
Valid from car Ass. Nr. 35055 		$3.01 2
