Hand-Brake Control

Ferrari 355 (2.7 Motronic)

Find Your Part

Ferrari 355 (2.7 Motronic) - HAND-BRAKE CONTROL

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
10418501 BRACKET $2.86 To Order
Photo Part No Description Price (each) Stock
10519424 WASHER D.6.4 X 11.95 X 1.6 $0.02 IN STOCK
Photo Part No Description Price (each) Stock
975354 KIT INTERRUTTORE FRENO STAZIONAMENTO $10.57 To Order
View All
HAND-BRAKE CONTROL of Ferrari Ferrari 355 (2.7 Motronic) Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
- 170701
BRAKE SHOE
As an alternative / See "INNER TRIMS CAR CODE" table for codes / of parts covered in leather or moquette.
IN STOCK 		$56.88 4
- 170701
BRAKE SHOE
As an alternative / /
IN STOCK 		$56.88 4
- 629965
LINING -See relevant table for
For leather colours see table / Valid till stock exhaustion 		- 1 Enquire
- 626854
LEATHER UPHOLSTERY
For leather colours see table / Valid after stock exhaustion of 629965.. 		- 1 Enquire
1 154095
HAND BRAKE LEVER
Without lining 		$1,765.28 1
2 897538
SCREW 		$1.52 4
3 127494
WASHER
IN STOCK 		$0.08 (88.2% off) 4
4 84653800
WASHER 10 X 18 X 2.5
IN STOCK 		$4.96 1
5 264555
SPLIT PIN 		- 1 Enquire
6 10418501
BRACKET 		$2.86 (51.4% off) 1
7 14059290
FLANGED NUT M6
IN STOCK 		$1.31 1
8 10519424
WASHER D.6.4 X 11.95 X 1.6
IN STOCK 		$0.02 (92% off) 1
9 975354
KIT INTERRUTTORE FRENO STAZIONAMENTO 		$10.57 1
10 114320
SUPPORT BRACKET 		$2.04 1
11 15896470
NUT 		$6.31 1
12 12601174
WASHER 		$0.06 (82.9% off) 1
13 62769800
WASHER D.5-14 X 2.5
ARRIVING SOON 		$0.21 (30% off) 2
14 141219
FRONT HANDBRAKE CABLE
IN STOCK 		$93.76 1
15 118552
ANCHORAGE FOR REAR CABLE 		$3.47 (44.7% off) 1
16 118553
HAND BRAKE CABLE RETAINIG
PLATE 		$54.01 1
17 16102314
NUT 		$0.06 (95.3% off) 2
18 104895
SPRING 		$31.50 1
19 141220
REAR HANDBRAKE CABLE
IN STOCK 		$78.24 (25.6% off) 1
20 10441290
BRACKET WITH SHEATH
IN STOCK 		$0.53 (68.5% off) 1
21 14059290
FLANGED NUT M6
IN STOCK 		$1.31 7
22 10519424
WASHER D.6.4 X 11.95 X 1.6
IN STOCK 		$0.02 (92% off) 7
23 143938
STOP LIMIT FOR HAND BRAKE SHEATH
BRAKE SHEATH 		$12.47 (79.1% off) 2
24 156916
BRAKE SHOES FIXING SCREW
L. mm. 29 		$84.87 (2.6% off) 2
25 156915
BRAKE SHOES FIXING SCREW
L. mm. 36 		$47.57 (56.6% off) 2
26 101277
SPRING 		$0.74 (85.9% off) 4
27 12625224
WASHER 		$0.06 (76% off) 4
28 101276
RETURN SPRING FOR BRAKE SHOES
SHOES 		$45.36 4
29 101285
SCREW
IN STOCK 		$54.62 2
30 101286
Nut for adjusting screw
IN STOCK 		$68.06 2
31 101279
SEAT FOR ADJUSTMENT SCREW 		$114.70 2
32 101280
Inner Control Lever 		$83.18 2
33 101281
Outer Control Lever 		$108.39 (30.1% off) 2
34 105270
Inner lever control fork 		$46.62 (58.7% off) 2
35 142861
HUB HOLDER SMALL BLOCK 		$260.49 2
36 142856
SCREW 		$4.68 4
37 101283
Pin for joint 		$25.57 2
38 101282
FIXING FORK TO INNER LEVER PIN
PIN
IN STOCK 		$12.60 2
39 10418501
BRACKET 		$2.86 (51.4% off) 6
40 170701
BRAKE SHOE
IN STOCK 		$56.88 4
