Electrical System - Valid For Usa

Ferrari 348 TB (1993)

Find Your Part

Ferrari 348 TB (1993) - Electrical System - Valid for USA

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
137665 FRONT CABLES $419.65 To Order
139573 FRONT CABLES -Valid for J- $367.28 To Order
Photo Part No Description Price (each) Stock
138914 FRONT HEADLIGHT CONNECTION CABLES $55.60 To Order
Photo Part No Description Price (each) Stock
140835 CABLE FOR FURTHER STOP LIGHT $64.29 To Order
Photo Part No Description Price (each) Stock
139367 CABLES FOR NUMBER PLATE LIGHTS $72.62 To Order
Photo Part No Description Price (each) Stock
134436 CABLES FOR ANTISKID DEVICES CONNECTION $878.38 To Order
Photo Part No Description Price (each) Stock
142178 FACIA PANEL CONNECTION CABLES $2,070.92 To Order
139887 FACIA PANEL CONNECTION CABLES $3,255.09 To Order
Photo Part No Description Price (each) Stock
146196 TESTER PUSH CABLE $14.65 To Order
Photo Part No Description Price (each) Stock
134430 LH DOOR CONNECTION CABLES $414.88 To Order
153783 L.H. DOOR CONNECTION CABLES $508.85 To Order
146740 LH DOOR CONNECTION CABLES $708.74 To Order
Photo Part No Description Price (each) Stock
153784 L.H. DOOR CONNECTION CABLES $435.62 To Order
146741 LH DOOR CONNECTION CABLES $548.06 To Order
134431 RH DOOR CONNECTION CABLES $411.19 To Order
Photo Part No Description Price (each) Stock
139524 CABLES FOR TUNNEL CONSOLE CONNECTION $118.90 To Order
134429 CABLES FOR TUNNEL-CONSOLE CONNECTION $325.11 To Order
Photo Part No Description Price (each) Stock
142179 REAR CABLES $448.37 To Order
140344 REAR CABLES $941.36 To Order
151559 REAR CABLES $1,104.97 To Order
Photo Part No Description Price (each) Stock
134432 ROOF LIGHT CONNECTION CABLES $14.71 To Order
Photo Part No Description Price (each) Stock
151912 CONNECTION CABLES FOR ENGINE UTILITIES $508.85 To Order
151333 CONNECTION CABLES FOR MOTOR UTILITIES $338.89 To Order
142747 CONNECTION CABLES FOR MOTOR UTILITIES $491.23 To Order
...and 1 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
139491 CABLES FOR LH MAIN BEARINGS CONNECTION $594.52 To Order
143207 CABLES FOR LH SIDE ENGINE CONNECTION $735.03 To Order
143207 CABLES FOR LH SIDE ENGINE CONNECTION $735.03 To Order
Photo Part No Description Price (each) Stock
139490 CABLES FOR R.H MAIN BEARING CONECTION $1,255.53 To Order
143206 CABLES FOR RH SIDE ENGINE CONNECTION $825.40 To Order
143206 CABLES FOR RH SIDE ENGINE CONNECTION $825.40 To Order
...and 4 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
140147 L.H. CABLES PROTECTION $29.16 To Order
Photo Part No Description Price (each) Stock
140148 R.H. CABLES PROTECTION $28.63 To Order
Photo Part No Description Price (each) Stock
134041 NUT $0.81 IN STOCK
Photo Part No Description Price (each) Stock
10519424 WASHER D.6.4 X 11.95 X 1.6 $0.02 IN STOCK
Photo Part No Description Price (each) Stock
11197774 WASHER $0.06 IN STOCK
Photo Part No Description Price (each) Stock
137668 LOW/HIGHT HEADLIGHT RELEASE CABLE $20.63 To Order
146768 SENSOR FIXING PLATE $172.91 To Order
Photo Part No Description Price (each) Stock
14202782 BLOCK -Valid for SA- $0.05 To Order
153142 CAR RADIO CABLES $211.04 To Order
Photo Part No Description Price (each) Stock
139944 GASKET $8.60 To Order
146611 TACHOMETRIC SENSOR WITH BUZZER $165.02 To Order
Photo Part No Description Price (each) Stock
154758 GASKET $10.54 To Order
14497705 WASHER -Valid for SA- Enquire To Order
Photo Part No Description Price (each) Stock
60991000 CLAMP $0.52 IN STOCK
168133 Screw M5 x 20 $0.87 IN STOCK
View All
Electrical System - Valid for USA of Ferrari Ferrari 348 TB (1993) Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
1 137665
FRONT CABLES
Valid for M. 2.7- 		$419.65 1
1 139573
FRONT CABLES -Valid for J-
Valid for M. 2.5- 		$367.28 1
2 138914
FRONT HEADLIGHT CONNECTION CABLES 		$55.60 2
3 140835
CABLE FOR FURTHER STOP LIGHT 		$64.29 1
4 139367
CABLES FOR NUMBER PLATE LIGHTS 		$72.62 1
5 134436
CABLES FOR ANTISKID DEVICES CONNECTION 		$878.38 1
6 142178
FACIA PANEL CONNECTION CABLES
Valid for M. 2.5- 		$2,070.92 1
6 139887
FACIA PANEL CONNECTION CABLES
Valid for M. 2.7- 		$3,255.09 1
7 146196
TESTER PUSH CABLE
Valid for M. 2.7- 		$14.65 1
8 134430
LH DOOR CONNECTION CABLES
Valid for M. 2.5 Valid for bellows 138903 See Table 118 Part. 22 		$414.88 1
8 153783
L.H. DOOR CONNECTION CABLES
Valid for M. 2.7 Valid after stock exhaustion of 146740 Valid for bellows assembly 153703 See Table 118 Part. 23 		$508.85 (10.3% off) 1
8 146740
LH DOOR CONNECTION CABLES
Valid for M. 2.7 Valid till stock exhaustion Valid for bellows 138903 See Table 118 Part. 22 		$708.74 1
9 153784
L.H. DOOR CONNECTION CABLES
Valid for M. 2.7 Valid after stock exhaustion of 146741 Valid for bellows assembly 153703 See Table 118 Part. 23 		$435.62 1
9 146741
LH DOOR CONNECTION CABLES
Valid for M. 2.7 Valid till stock exhaustion Valid for bellows 1 38903 See Table 118 Part. 22 		$548.06 1
9 134431
RH DOOR CONNECTION CABLES
Valid for M. 2.5 Valid for bellows 138903 See Table 11 8 Part. 22 		$411.19 1
10 139524
CABLES FOR TUNNEL CONSOLE CONNECTION
Valid for M. 2.7 		$118.90 1
10 134429
CABLES FOR TUNNEL-CONSOLE CONNECTION
Valid for M. 2.5 		$325.11 1
11 142179
REAR CABLES
Valid for M. 2.5 		$448.37 1
11 140344
REAR CABLES
Valid for M. 2.7 Valid for rear battery cars 		$941.36 1
11 151559
REAR CABLES
Valid for M. 2.7 Valid for front battery cars 		$1,104.97 1
12 134432
ROOF LIGHT CONNECTION CABLES 		$14.71 1
13 151912
CONNECTION CABLES FOR ENGINE UTILITIES
Valid for M. 2.7 Valid for front battery cars Valid from engine Nr. 30738 		$508.85 1
13 151333
CONNECTION CABLES FOR MOTOR UTILITIES
Valid for M. 2.7 Valid for front battery cars Valid till engine Nr. 30737 		$338.89 1
13 142747
CONNECTION CABLES FOR MOTOR UTILITIES
Valid for M. 2.7 Valid for rear battery cars 		$491.23 1
13 134433
CONNECTION CABLES FOR MOTOR UTILITIES
Valid for M. 2.5 		$173.40 1
14 139491
CABLES FOR LH MAIN BEARINGS CONNECTION
Valid for M. 2.5 		$594.52 1
14 143207
CABLES FOR LH SIDE ENGINE CONNECTION
Valid for ZA from car Nr. 90966- 		$735.03 1
14 143207
CABLES FOR LH SIDE ENGINE CONNECTION
Valid for M. 2.7 		$735.03 1
15 139490
CABLES FOR R.H MAIN BEARING CONECTION
valid for m.2.5 		$1,255.53 1
15 143206
CABLES FOR RH SIDE ENGINE CONNECTION
valid for m.2.5 		$825.40 1
15 143206
CABLES FOR RH SIDE ENGINE CONNECTION
Valid for M. 2.7 Not for SA and ZA 		$825.40 1
15 134434
CABLES FOR RH MAIN BEARINGS CONNECTION
Valid for M. 2.5 Not for catalyzed cars 		$2,139.07 1
15 139490
CABLES FOR R.H MAIN BEARING CONECTION
Valid for M. 2.5 Valid for catalyzed cars 		$1,255.53 1
15 143206
CABLES FOR RH SIDE ENGINE CONNECTION
Valid for ZA from car Nr. 90966 		$825.40 1
15 146607
CABLES FOR RH MAIN BEARINGS CONNECTION
Valid for M. 2.7 Valid for SA Valid for ZA till car Nr. 90965 		$1,491.08 1
16 140147
L.H. CABLES PROTECTION 		$29.16 1
17 140148
R.H. CABLES PROTECTION 		$28.63 1
18 134041
NUT
IN STOCK 		$0.81 4
19 10519424
WASHER D.6.4 X 11.95 X 1.6
IN STOCK 		$0.02 (92% off) 4
20 11197774
WASHER
IN STOCK 		$0.06 (80% off) 4
21 137668
LOW/HIGHT HEADLIGHT RELEASE CABLE 		$20.63 1
21 146768
SENSOR FIXING PLATE
Valid for SA 		$172.91 1
22 14202782
BLOCK -Valid for SA-
Valid for SA 		$0.05 (80% off) 2
22 153142
CAR RADIO CABLES 		$211.04 1
23 139944
GASKET 		$8.60 1
23 146611
TACHOMETRIC SENSOR WITH BUZZER
Valid for SA 		$165.02 1
24 154758
GASKET 		$10.54 1
24 14497705
WASHER -Valid for SA-
Valid for SA 		- 2 Enquire
25 60991000
CLAMP
IN STOCK 		$0.52 5
25 168133
Screw M5 x 20
valid for SA
IN STOCK 		$0.87 (30.4% off) 2
26 10519424
WASHER D.6.4 X 11.95 X 1.6
Valid for SA
IN STOCK 		$0.02 (92% off) 2
27 14059290
FLANGED NUT M6
Valid for SA
IN STOCK 		$1.31 2
28 148406
CABLES FOR DIURNAL LIGHTS CONNECTION
Valid for CDN 		$23.44 1
29 139944
GASKET 		$8.60 1
30 154758
GASKET 		$10.54 1
31 60991000
CLAMP
IN STOCK 		$0.52 5
